Product Summary
The ADS7805PB is a complete 16-bit sampling A/D using state-of-the-art CMOS structures. It contains a complete 16-bit, capacitor-based, SAR A/D with S/H, reference, clock, interface for microprocessor use, and three-state output drivers. The ADS7805PB is specified at a 100kHz sampling rate, and guaranteed over the full temperature range. Lasertrimmed scaling resistors provide an industry standard ±10V input range, while the innovative design allows operation from a single +5V supply, with power dissipation under 100mW. The 28-pin ADS7805PB is available in a plastic 0.3 DIP and in an SOIC, both fully specified for operation over the industrial -25℃ to +85℃ range.
Parametrics
ADS7805PB absolute maximum ratings: (1)Analog Inputs: VIN: ±25V; (2)CAP: +VANA +0.3V to AGND2 –0.3V; (3)REF: Indefinite Short to AGND2, Momentary Short to VANA; (4)Ground Voltage Differences: DGND, AGND1, AGND2: ±0.3V; (5)VANA: 7V; (6)VDIG to VANA: +0.3V; (7)VDIG: 7V; (8)Digital Inputs: -0.3V to +VDIG +0.3V; (9)Maximum Junction Temperature: +165℃; (10)Internal Power Dissipation: 825mW; (11)Lead Temperature (soldering, 10s): +300℃.
Features
ADS7805PB features: (1)100kHz min SAMPLING RATE; (2)STANDARD ±10V INPUT RANGE; (3)86dB min SINAD WITH 20kHz INPUT; (4)±3.0 LSB max INL; (5)DNL: 16-bits No Missing Codes; (6)SINGLE +5V SUPPLY OPERATION; (7)PIN-COMPATIBLE WITH 12-BIT ADS7804; (8)USES INTERNAL OR EXTERNAL REFERENCE; (9)FULL PARALLEL DATA OUTPUT; (10)100mW max POWER DISSIPATION; (11)28-PIN 0.3 PLASTIC DIP AND SOIC.
Diagrams
| Image | Part No | Mfg | Description |  |
Pricing (USD) |
Quantity | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 |
 ADS7805PB |
Texas Instruments |
ADC (A/D Converters) 16-Bit 10us Sampling CMOS |
Data Sheet |
|
|
||||||||||||
|
ADS7805PBG4 |
Texas Instruments |
ADC (A/D Converters) 16-Bit 10us Sampling CMOS |
Data Sheet |
|
|
||||||||||||
